98414-G06-10ULF by amphenol communications solutions (fci)
Image is representational - see manufacturer specifications
Amphenol Communications Solutions (FCI) Authorized Distributor

98414-G06-10ULF

A 10-position, 2.00mm pitch, vertical through-mount header with 0.76μm gold-plated contacts. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 98414-G06-10ULF is a 10-position vertical through-mount header from the MINITEK product family. It features copper alloy terminals with 0.76μm Gold/GXT plating on the contact area and 2μm matte tin on the tails, over a 1.27μm nickel underlayer. This header is designed with a 4.00mm post length and a 2.50mm tail length. The housing is constructed from high-temperature thermoplastic rated UL-94V0, ensuring it can withstand wave soldering processes up to 260°C. This RoHS-compliant component is suitable for various board-to-board connections requiring reliable performance.

Search Keywords: 98414G0610ULF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (FCI)
Part No:
98414-G06-10ULF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1128
Package Type:
TUBE
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2 mm
Number of Contacts:
10
Maximum Voltage Rating:
200,200 VDC|VAC
Maximum Current Rating:
2/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 125 °C

IN STOCK: 3,433

Ships today, if you order in

On Order: 3,384   can ship 1/1/27

Minimum Order Quantity: 50

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
50
$0.826
250
$0.755
500
$0.724
1,128
$0.688
3,384
$0.640
5,640
$0.617
7,896
$0.603
10,152 +
$0.591
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
