Image is representational - see mfr. specs

AT04-12PA-PM05

Amphenol Sine Systems

12-Way Panel Mount Receptacle with Flange ...

Datasheet

RoHS Compliant

EACH Packaging

Certificate of Compliance Guarantee

DESCRIPTION

AT04-12PA-PM05 is a 12-position receptacle connector with flange and pin configuration, engineered as part of Amphenol Sine Systems' PanelMate™ AT product family. The connector features a threaded insert design with a gasket and standard diameter rear seal (red), housed in a grey body, and incorporates keyed design (Keyed A) for secure mating. With a contact size of 16 and rated amperage of 13A, it is designed for rapid and secure panel mounting with a one-piece sealed flanged design. The connector's durable, high-temperature silicone facial seal provides protection from lubricating oils, hydraulic fluids, and fossil fuels, making it suitable for harsh industrial environments. This connector accepts A Series™ components and is comparable with other industry standard mating connectors, requiring a wedgelock (AW12P) for complete assembly.

Product Highlights:

Potential Applications:

Search Keywords: AT0412PAPM05

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AT04-12PA-PM05

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538908180

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
