2302-H-RC

Inductor High Current Toroid 12uH/7.8uH 15% 1KHz 19.1A 5mOhm DCR RDL ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 2302-H-RC is a high-current toroid inductor designed for DC/DC converter and EMI filter applications in power electronics. It features an inductance of 12 µH (±15% @ 1 kHz) with a rated DC current of 19.1 A and an inductance value of 7.8 µH at rated current, maintaining a maximum DC resistance of 0.005 O. The device is optimized for low radiation and low core loss characteristics, with horizontal mounting capability (indicated by the -H designation), and operates reliably across a temperature range of -55 °C to +105 °C. Its compact dimensions (0.56 in. × 1.18 in. × 0.066 in.) and RoHS-compliant construction make it ideal for space-constrained power supply designs requiring high current capacity with minimal thermal rise.

Search Keywords: 2302HRC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
2302-H-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
HN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
36
Package Type:
OTHER
Inductance:
12(OCL)/7.8 uH
Type:
High current
Impedance:
N/A
Lead Pitch:
29.97 mm
Tolerance:
15 %
Technology:
Toroid
Maximum DC Resistance:
5 mOhm
Maximum DC Current:
19.1 A
Protection Style:
N/A
Packaging:
N/A

IN STOCK: 252

Can Ship immediately

Minimum Order Quantity: 36

Multiple: 36

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
36
$3.63
108
$2.82
252
$2.64
504
$2.53
1,008
$2.52
2,520
$2.51
5,004
$2.50
7,524 +
$2.49
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
