530614B00000G by boyd laconia llc
Image is representational - see mfr. specs

530614B00000G

Boyd Laconia LLC

The 530614B00000G is an aluminum, channel-style board-level heat sink designed for cooling TO-220 and TO-220-single gauge semiconductor devices. ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 530614B00000G is a board-level channel heat sink intended for the thermal management of TO-220 and TO-220-single gauge packaged devices. Constructed from aluminum with a black anodize finish, this heat sink has a height of 29.97 mm, a width of 25.40 mm, and a length of 12.70 mm. It can be mounted either horizontally or vertically, offering design flexibility. Based on performance data, it provides a thermal resistance of approximately 10 °C/Watt under natural convection. This RoHS compliant component is ideal for applications requiring efficient heat dissipation from power transistors and voltage regulators in a compact footprint.

Search Keywords: 530614B00000G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Boyd Laconia LLC
Part No:
530614B00000G
Alias/AKA:
001725
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8473309000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
Bulk
Device Cooled:
TO-220
Attachment Method:
Screw
Dimension:
25.4 x 29.97 x 12.7 mm
Thermal Resistance:
16.7 °C/W
Finish:
Black Anodized

IN STOCK: 3,526

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
10
$3.02
50
$2.69
250
$2.47
500
$2.38
2,000
$2.21
4,000 +
$2.20
Suppliers Standard Package
