559-3001-007F

The 559-3001-007F is a 2-leaded, bi-color (Red/Green) snap-in LED panel mount indicator designed for a 0.250-inch mounting hole. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 559-3001-007F is a bi-color, 2-leaded snap-in LED indicator for panel mounting. It emits red light with a peak wavelength of 660 nm and green light at 565 nm, with typical luminous intensities of 90 mcd and 40 mcd, respectively. The indicator operates with a typical forward current of 20 mA and has corresponding forward voltages of 1.8V for red and 2.1V for green. It features a 60-degree viewing angle and comes with 14-inch, 24 AWG wire leads. This RoHS compliant indicator operates over a wide temperature range of -55°C to +100°C, making it suitable for demanding applications like data-center infrastructure, communications equipment, and electronic test instruments.

Search Keywords: 5593001007F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
559-3001-007F
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541402000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
BAG
Mounting:
Panel
Dimension:
15.88(Max) x 7.14 mm
Type:
Bi-Color
Maximum Forward Voltage per Color:
2.1(Typ)/1.8(Typ) V
Color:
Green/Red
Peak Wavelength:
565/660 nm
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
N/A
Intensity:
40,90 mcd
Viewing Angle:
60 °
Maximum Forward Current:
30/40 mA

IN STOCK: 79

Can Ship immediately

Buy all 79 in-stock or the regular minimum order quantity of 100

On Order: 600   can ship 12/17/26

Stock lot only: 79

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$2.15
100
$1.96
300
$1.93
500
$1.72
1,000
$1.57
2,500
$1.56
5,000
$1.48
7,500
$1.47
10,000 +
$1.46
