568-0721-111F by dialight
Image is representational - see mfr. specs

568-0721-111F

Dialight

568 Series CBI 2x4mm Rect 4hx1w Bicolor RO/G ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 568-0721-111F is a 4×1 rectangular CBI (Quad-level) LED indicator block manufactured by Dialight, designed for multi-color status indication applications. This through-hole component features four individual LED positions (POS. 1 through POS. 4), each capable of displaying red, yellow, or green light based on the specific configuration. The device operates at 25°C ambient temperature with luminous intensity ranging from 1.1 to 12.5 mcd depending on color, forward voltage specifications of 1.7 to 2.8 V at 20 mA, and peak wavelengths of 565 nm (green), 589 nm (yellow), and 635 nm (red). The component features a standard hole pattern with 0.100 inch (2.54 mm) spacing and is RoHS compliant, making it suitable for industrial control panels, equipment status displays, and indicator applications requiring compact multi-color LED arrays.

Search Keywords: 5680721111F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
568-0721-111F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541402000
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
BAG
Dimension:
5.08(Max) x 18.44 x 12.7 mm
Category:
Standard LED
Color:
Green/Red
Dominant Wavelength:
N/A
Color Temperature:
N/A

IN STOCK: 0

On Order: 315   can ship 5/14/26

Minimum Order Quantity: 10

Multiple: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
10
$6.26
100
$3.51
250
$3.24
500
$2.72
1,000 +
$2.51
Log in for special pricing Click for Quote Price Match Request
