76RSB10ST by grayhill

76RSB10ST

Grayhill

Switch DIP ON OFF SPST 10 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRAYHILL part 76RSB10ST is a high-quality DIP switch designed for ON/OFF functionality. This Single Pole Single Throw (SPST) switch features a recessed rocker design for easy operation. It has a rating of 0.15A at 30VDC and is equipped with PC pins for secure mounting. With a lifespan of 2000 cycles per switch, this component is reliable and durable for long-term use. It has a pitch of 2.54mm and is designed for easy installation with thru-hole mounting. This switch comes in a convenient tube packaging for efficient storage and handling.

Search Keywords: 76RSB10ST

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
76RSB10ST
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
9
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Recessed Rocker
Actuator Length:
0 mm
Number of Positions:
10
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.15@30VDC A
Contact Plating:
Gold/Nickel Barrier
Terminal Pitch:
2.54 mm

IN STOCK: 1,008

Ships today, if you order in

On Order: 18   can ship 12/26/25

Minimum Order: 9

Multiple: 9

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
9
$6.056
54
$5.387
108
$4.779
252
$4.460
504
$4.244
1,008
$4.048
2,502
$3.821
5,004 +
$2.760
