DBMM-25P-L by itt cannon
Image is representational - see manufacturer specifications
ITT CANNON Authorized Distributor

DBMM-25P-L

Conn D-Subminiature PIN 25 POS Solder RA Thru-Hole 25 Terminal 1 Port ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The ITT CANNON part DBMM-25P-L is a D-Subminiature connector with 25 pins, designed for soldering onto a circuit board in a right angle orientation. This connector features 25 terminals for reliable connectivity and is designed for use in a single port application.

Search Keywords: DBMM25PL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
DBMM-25P-L
Alias/AKA:
051522-0037
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
B
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 150 °C

IN STOCK: 6

Ships today, if you order in

MOQ for out of Stock Qty: 25

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
1
$63.83
5
$39.17
10
$38.41
25
$37.66
50
$37.29
75
$36.92
100 +
$36.54
Log in for special pricing
