142-0761-801 by johnson / cinch connectivity solutions

142-0761-801

Johnson / Cinch Connectivity Solutions

SMA High Freq End Launch Jack Assembly, PCB Mount ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Johnson/Cinch Connectivity Solutions part 142-0761-801 is a high-quality SMA connector that is designed to provide reliable and efficient connectivity in a variety of applications. With a frequency range of 0Hz to 26.5GHz, this connector is capable of handling a wide range of signals with ease. It features a 50Ohm impedance, making it compatible with a variety of devices and systems. The connector is designed for soldering and features a straight edge mount for easy installation. It offers a reverse polarity configuration with a gold-plated finish that ensures excellent conductivity and resistance to corrosion. Whether you're working on a professional project or a personal electronics endeavor, the Johnson/Cinch 142-0761-801 is a dependable choice that will deliver consistent performance.

Search Keywords: 1420761801

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0761-801
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Bag
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 26.5 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
14.07 x 4.55 x 4.55 mm

IN STOCK: 39

Can Ship immediately

On Order: 1,000   can ship 1/12/26

Minimum Order: 5

Factory Lead-Time 8 Weeks

Price (CAD)

Qty
Unit Price
5
$22.204
25
$16.354
50
$14.808
100
$13.904
250
$12.756
500
$11.577
1,000 +
$11.025
