CN202J3RS215Q7 by littelfuse/c-k
Image is representational - see mfr. specs

CN202J3RS215Q7

Littelfuse/C&K

Double Pole Power Rocker Switch ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

CN202J3RS215Q7 is a double pole power rocker switch designed for industrial and commercial applications. The switch features a J3 illuminated rocker actuator with red illumination (R option) and silver contact material (Q rating), providing 16A @ 125V AC or 10A @ 250V AC switching capacity. It is constructed with 6/6 nylon housing (UL94V-2) in black matte finish, silver-plated copper alloy terminals, and operates reliably over a temperature range of -20°C to +85°C with an electrical life of 10,000 make-and-break cycles at full load. The switch offers snap-in mounting compatibility and is RoHS compliant, making it suitable for appliances, office equipment, computers, industrial machines, HVAC units, and transportation systems where robust, illuminated switching control is required.

Search Keywords: CN202J3RS215Q7

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
CN202J3RS215Q7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
TRAY
Mounting:
Panel Mount
Pole Throw Configuration:
2P1T (DPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
16@125VAC@(CSA/UL) A
Actuator Style:
Curved Rocker
Actuator Color:
Red
Bezel Color:
Black
Illumination:
Red,Neon Lamp
Terminal Type:
Quick Connect
Body Orientation:
Straight

IN STOCK: 724

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 500

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
5
$5.12
100
$4.33
250
$4.16
500
$4.11
1,000
$4.07
1,500
$4.05
2,000 +
$4.03
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
