LRS-600-24

Name: LRS-600-24
Brand: Mean Well
SKU: 56536643
Availability: InStock

The LRS-600-24 is a 600W single-output enclosed-type switching power supply that provides a 24V DC output. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The LRS-600-24 is a 600W single-output enclosed-type power supply designed to deliver a stable 24V DC output at up to 25A. It operates with a selectable AC input range of 90-132VAC or 180-264VAC and achieves a typical efficiency of 91%. Featuring a 1U low profile design, it incorporates forced air cooling via a built-in fan, enabling operation at full load in temperatures up to 65Â°C. The unit is equipped with comprehensive protections against short circuit, overload, over voltage, and over temperature, and is built to withstand a 5G vibration test. This power supply is a high price-to-performance solution for industrial automation machinery, control systems, and various electronic instruments.

Product Highlights:

Potential Applications:

Search Keywords: LRS60024

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

MEAN WELL

Part No:

LRS-600-24

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504409540

COO:

ECCN:

EAR99
