RT-50C

Name: RT-50C
Brand: Mean Well
SKU: 43123167
Price: 19.78 USD
Availability: InStock

AC-DC Triple output enclosed power supply; Output +5Vdc at 4A +15Vdc at 1.5A -15Vdc at 0.5 ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The RT-50C is a 50W AC/DC Enclosed switching power supply featuring Constant voltage mode output for 3 channels. RT-50C has 2 input voltage operation ranges selected by a switch from 88 to 132VAC and 176 to 264VAC. Voltage output is adjustable for channel 1 from 4.75 to 5.5V and output current range from .5 to 5A- .2 to 2A-.1 to 1A for 3 channels with rated currents of 4A-1.5A-.5A. Thanks to the high efficiency up to 78%, it is able of operating from -25 to +70 ℃ case temperature under free air convection. RT-50C uses a LED indicator for power on with all channels using 105°C long life electrolytic capacitors makes it withstands 5G vibration test. The RT-50C has a 3 years factory warranty.

Product Highlights:

Potential Applications:

Search Keywords: RT50C

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

MEAN WELL

Part No:

RT-50C

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504409510

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
