MCP1525T-I/TT by microchip technology

MCP1525T-I/TT

Microchip Technology

Voltage Reference - Precision - Series - Fixed - 2.5V - 8mA - SOT-23-3 - 3-Pin. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MCP1525T-I/TT is a low power, high precision voltage reference in 3 pin SOT-23 package. This voltage reference is normally used in 3V to 5V systems where wide variations in supply voltage exists and need to minimize power dissipation. The MCP1525 use combination of an advanced CMOS circuit design and EEPROM trimming to provide an initial tolerance of 1% and temperature stability of 50ppm/°C. This device offers clear advantage over traditional zener techniques in terms of stability across time and temperature.

Search Keywords: MCP1525TITT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP1525T-I/TT
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
REEL
Maximum Temperature Coefficient:
50 ppm/°C
Mounting:
Surface Mount
Family:
MCP1525
Maximum Output Current:
8(Typ) mA
Initial Accuracy:
1 %
Maximum Input Voltage:
7 V
Load Regulation:
1.3 mV/ mA
Line Regulation:
350 uV/V
Dimension:
2.9 x 1.3 x 0.95 mm

IN STOCK: 39,450

Ships today, if you order in

Minimum Order: 500

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
500
$1.140
1,000
$1.134
3,000
$1.130
6,000
$1.124
9,000
$1.118
12,000
$1.114
15,000 +
$1.108
