FAN3227TMX

The FAN3227TMX is a dual-channel, non-inverting, 2 A low-side gate driver with TTL input thresholds, designed for driving N-channel MOSFETs. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The FAN3227TMX is a dual 2 A, high-speed, low-side gate driver designed to drive N-channel enhancement-mode MOSFETs in switching applications. It features two independent non-inverting channels with TTL-compatible input thresholds and separate enable pins. The driver operates over a wide 4.5 V to 18 V supply range and provides high peak currents, typically 3 A sink/source at a 12 V supply, to minimize switching losses. It incorporates MillerDriveâ„¢ technology for high current during the Miller plateau stage and features propagation delays matched within 1 ns between channels. These characteristics make the FAN3227TMX ideal for synchronous rectifiers, switch-mode power supplies, DC-to-DC converters, and motor control applications.

Search Keywords: FAN3227TMX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
FAN3227TMX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390070
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2500

IN STOCK: 13,185

Can Ship immediately

Minimum Order Quantity: 500

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
500
$0.755
1,000
$0.725
2,500
$0.690
5,000
$0.688
7,500
$0.686
10,000
$0.681
15,000
$0.680
25,000 +
$0.673
Supplier's Standard Package
