AEP52024 by panasonic electronic components

Image is representational - see mfr. specs

AEP52024

The AEP52024 is a 20A TM type high-capacity DC power relay featuring a 1 Form A contact arrangement and a 24V DC nominal coil voltage. ...

Datasheet

RoHS Compliant

Discontinued & Replaced

Certificate of Compliance Guarantee

DESCRIPTION

The AEP52024 is a 20A TM type high-capacity EP relay designed for high-voltage, high-current DC switching. It operates on a 24V DC coil and has a 1 Form A contact configuration rated for a nominal switching capacity of 20A at 400V DC. The relay's hermetically sealed construction with mixed hydrogen gas allows for a maximum contact voltage of 1,000V DC, ensuring high reliability and stable contact resistance. Key performance characteristics include a maximum operate time of 50ms, a mechanical life of at least 200,000 cycles, and an operating temperature range of -40°C to +80°C. This makes the AEP52024 suitable for demanding applications like solar power systems, battery charge/discharge control, and inverter control.

Product Highlights:

Potential Applications:

Search Keywords: AEP52024

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Panasonic Electronic Components

Part No:

AEP52024

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536410020

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
