AQS225R2SX by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

AQS225R2SX

Solid State Relay 50mA 1.5V DC-IN 0.07A 80V AC/DC-OUT 16-Pin SOP T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

AQS225R2SX is a 4-channel (4 Form A) PhotoMOS relay designed for multi-circuit switching applications in a compact SOP16-pin package. It features low on-resistance of 10.5O typical, output capacitance of 4.5pF typical, and fast turn-on time of 0.04ms typical, making it suitable for RF and low-level analog signal control. The device supports an 80V load voltage with 70mA continuous load current and provides 1,500V AC I/O isolation voltage. Operating temperature ranges from -40°C to +85°C, ensuring reliable performance across various environments. Common applications include measuring and testing equipment such as IC testers, probe cards, and in-circuit testers, as well as communication, broadcasting, and medical equipment.

Search Keywords: AQS225R2SX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQS225R2SX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1000
Output Type:
AC,DC
Maximum Output Voltage:
80 V
Maximum Output Current:
0.07 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Surface Mount
Circuit Arrangement:
4 Form A
Dimension:
10.37 x 4.4 x 2.1 mm
  Different packaging options available.  See Alternatives

IN STOCK: 0

MOQ for out of Stock Qty: 250

Factory Lead-Time 37 Weeks

Price (USD)

Qty
Unit Price
250
$20.55
500
$20.50
750
$20.13
1,000 +
$19.73
Supplier's Standard Package
