AQZ202

Solid State Relay 50mA 1.5V DC-IN 3A 48V AC/DC-OUT 4-Pin SIL Carton ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AQZ202 is an AC/DC dual-use PhotoMOS solid-state relay designed for switching applications requiring both AC and DC load capability. It features a slim SIL4-pin package with extremely low on-resistance of 0.11 O (typical) and a high I/O isolation voltage of 2,500 Vrms, providing excellent electrical isolation between input and output circuits. The device operates with an LED forward current range of 5–30 mA and supports peak AC/DC load voltages up to 60 V with continuous load currents of 3.0 A, making it suitable for industrial control applications. With a maximum off-state leakage current of 10 µA, low thermoelectric force, and no contact noise or arcing, the AQZ202 eliminates the need for protective diodes and external power supplies in drive circuits. Typical applications include traffic signal control, measuring instruments, and industrial machine automation, where reliable, silent switching and high isolation are essential.

Search Keywords: AQZ202

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQZ202
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
25
Output Type:
AC,DC
Maximum Output Voltage:
60 V
Maximum Output Current:
3 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Through Hole
Circuit Arrangement:
1 Form A
Dimension:
21 x 3.5 x 12.5 mm

IN STOCK: 600

Can Ship immediately

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 54 Weeks

Price (USD)

Qty
Unit Price
25
$6.66
50
$6.49
100
$6.38
250
$6.34
500
$6.32
1,000
$6.31
2,500
$6.29
5,000 +
$6.27
