AXT610124 by panasonic electronic components
Image is representational - see mfr. specs

AXT610124

Panasonic Electronic Components

Conn Board to Board HDR 10 POS 0.4mm Solder ST SMD T/R ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AXT610124 is a 10-pin narrow pitch header connector designed for board-to-FPC (Flexible Printed Circuit) applications with a 0.4 mm pitch and 1.0 mm mated height. The connector features a space-saving design with a width of 3.6 mm and incorporates "Tough Contact" construction with Ni barrier and bellows contact design for high contact reliability and strong resistance to various environmental conditions. It includes a simple lock structure that provides tactile feedback for reliable mating and unmating operations. The connector is rated for 0.3 A per pin contact (maximum 5 A total) at 60 V AC/DC, with dielectric strength of 150 V AC for 1 minute. This connector is ideal for mobile devices and industrial equipment where space constraints and reliable interconnection are critical requirements.

Search Keywords: AXT610124

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AXT610124
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Type:
Board to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Surface Mount
Pitch:
0.4 mm
Number of Contacts:
10
Maximum Voltage Rating:
60,60 VDC|VAC
Maximum Current Rating:
0.3/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C

IN STOCK: 1,750

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
50
$0.6468
250
$0.5592
1,000
$0.5092
3,000
$0.4713
6,000
$0.4489
9,000
$0.4362
12,000
$0.4351
15,000 +
$0.4158
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
