EXB-V8V103JV by panasonic

EXB-V8V103JV

Panasonic

Res Thick Film Array 10K Ohm 5% ±200ppm/°C ISOL 8-Pin 1206(4 X 0603) Concave SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC part EXB-V8V103JV is a highly reliable and compact Res Thick Film Array. It has a resistance value of 10K Ohm with a tolerance of 5%. The part is designed to have a temperature coefficient of ±200ppm/°C for accurate and stable performance. With an 8-pin 1206 package, it is soldered onto the PCB using surface mount technology (SMD). The package is in a concave shape and consists of 4 X 0603 resistors. The part is supplied in tape and reel packaging, making it suitable for automatic pick and place assembly.

Search Keywords: EXBV8V103JV

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
EXB-V8V103JV
RoHS:
Yes
HTS:
8533210020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000
Package Type:
Reel
Case Size:
1206
Circuit Designator:
ISOL
Number of Resistors:
4
Number of Terminals:
8
Power Rating:
N/A
Power Rating per Resistor:
0.063 (1/16) W
Resistance Value:
10 KOhm
Tolerance:
5 %
Temperature Coefficient:
±200 ppm/°C
Termination Style:
Concave

IN STOCK: 7,365

Ships today, if you order in

On Order: 30,000   can ship 12/31/25

Minimum Order: 5000

Multiple: 5000

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5,000
$0.0256
10,000
$0.0250
25,000
$0.0242
50,000
$0.0239
100,000
$0.0235
150,000
$0.0234
250,000
$0.0233
500,000 +
$0.0232
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
