1777109 by phoenix contact

1777109

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 5 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1777109 is a PCB header designed for reliable electrical connections. It features a nominal current of 12 A and a rated voltage (III/2) of 320 V, making it suitable for a variety of applications. The nominal cross-section is 2.5 mm², with 5 positions and a pitch of 5.08 mm. The headers are colored green and have a contact surface coated with tin for improved conductivity. They are designed for wave soldering mounting and have a linear pinning layout with solder pins measuring 3.9 mm in length.

Search Keywords: 1777109

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1777109
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
5
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 59

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 10 Weeks

Price (CAD)

Qty
Unit Price
5
$6.662
50
$5.544
100
$5.467
250
$5.007
500
$4.885
1,000
$4.808
2,500
$4.686
5,000 +
$4.625
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
