SNT-100-BK-T-H by samtec

SNT-100-BK-T-H

Samtec

Jumper (Busbar)- Shunt - Jumper - TSW, MTSW, TLW, DW, EW, ZW, HW, & TSM Series Headers - 2.54 mm. ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SNT-100-BK-G is a 2-position Jumper Shunt with 10µinch gold-plated phosphor bronze contacts. It is made with black glass filled polyester insulator. It mates with TSW/HTSW/MTSW/HMTSW/TLW/DW/EW/ZW/HW/TSM/BST/PHT series connectors. Operating temperature range is from -55 to 125°C.

Search Keywords: SNT100BKTH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
SNT-100-BK-T-H
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Type:
Shunt
Pitch:
2.54 mm
Number of Contacts:
2
Maximum Voltage Rating:
N/A
Maximum Current Rating:
4.3/Contact A
Operating Temperature:
-55 to 125 °C

IN STOCK: 15,009

Can Ship immediately

Manufacturer Stock: 27,227   can ship 12/5/25

Minimum Order: 250

Factory Lead-Time 2 Weeks can ship 12/4/25

Price (CAD)

Qty
Unit Price
250
$0.2047
1,000
$0.1295
2,500
$0.1215
5,000
$0.1006
10,000
$0.1002
25,000
$0.0996
50,000
$0.0990
100,000 +
$0.0986
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
