FSMCTTR by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

FSMCTTR

TE Connectivity / Alcoswitch Brand

Switch Tactile OFF (ON) SPST Round Button Gull Wing 0.02A 15VDC 1.56N SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

FSMCTTR is a low profile surface mount tactile switch from the FSMCT Series, designed for reliable momentary contact applications. It features an SPST configuration with an actuation force of 160±50gf and a life expectancy of up to 1,000,000 cycles. The switch has a contact rating of 20mA @ 15VDC, initial contact resistance of 100 milliohms max, and insulation resistance of 100 megaohms @ 100VDC minimum. Operating temperature ranges from -20°C to +85°C, with a compact footprint of 5.0mm x 5.0mm. The nylon UL94V-0 rated case and nickel silver cover ensure durability, making it suitable for consumer electronics, portable devices, and industrial control panels.

Product Highlights:

  • Switch - Mechanical
  • Tactile
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Contact Rating = 20mA
  • Operating Function = Off [On]

Search Keywords: FSMCTTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
FSMCTTR
Alias/AKA:
8-1437565-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536908585
COO:
CH
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
4000
Package Type:
Reel
Dimension:
5.2 x 6.4 x 1.5 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
Off (On)
Actuator Style:
Round Button
Operating Force:
1.56 N
Contact Rating @ Voltage:
0.02@15VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
Gull Wing
Seal Location:
N/R

IN STOCK: 77,800

Can Ship immediately

Minimum Order Quantity: 500

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
500
$0.5894
1,000
$0.5463
4,000
$0.5337
8,000
$0.5326
12,000
$0.5316
16,000
$0.5295
28,000
$0.5285
52,000 +
$0.5274
Reel Package
