MTG206P by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

MTG206P

TE Connectivity / Alcoswitch Brand

Switch Toggle ON OFF ON DPDT Short Lever Wire Lug 6A 250VAC 28VDC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MTG206P is a DPDT (double-pole double-throw) toggle switch from the Alcoswitch Green Series, featuring a long bat actuator and wire lug terminals for secure connections. The switch is rated for 6A at 125VAC, 3A at 250VAC, and 4A at 28VDC, with an initial contact resistance of 20 milliohms maximum and break-before-make contact timing. It operates reliably across a temperature range of -20°C to +80°C and demonstrates robust mechanical life expectancy of 80,000 cycles at 125VAC (6A resistive load) and 60,000 cycles at 28VDC (4A resistive load). The switch is constructed with gold-flashed silver contacts, chrome-plated copper alloy actuator, and thermoset 94V-0 case material, making it suitable for industrial control panels, automotive applications, and general-purpose switching where reliable DPDT functionality is required.

Product Highlights:

  • MTG Series
  • Double Pole - Double Throw Configuration (Pole-Throw)
  • Current Rating = 6 Amps.
  • Mount Style = Panel
  • Termination Type = Vertical, Wire Lugs

Search Keywords: MTG206P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
MTG206P
Alias/AKA:
2-1437559-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
6@125VAC A
Actuator Style:
Short Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
13 x 13 x 36.39 mm
Operating Temperature:
-20 to 80 °C

IN STOCK: 124

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 30 Weeks
