1057290-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1057290-1

TE Connectivity / AMP Brand

N Type Connector Receptacle, Female Socket 50 Ohm Panel Mount Solder ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1057290-1 is a RF Connectors / Coaxial Connectors N ST JCK-REC 4HF PST Connector Style N Type Connector Type Receptacle, Female Socket Contact Termination Solder Shield Termination Solder Impedance 50 Ohm Mounting Type Panel Mount Mounting Feature Flange Fastening Type Threaded Frequency - Max 11GHz Number of Ports 1 Features Extended Insulation Housing Color Silver Body Material Brass Body Finish Nickel Center Contact Plating Gold Dielectric Material Polytetrafluoroethylene (PTFE) Operating Temperature -65°C ~ 165°C

Product Highlights:

  • Connector
  • Jack
  • Terminate To Printed Circuit Board
  • Body Style = Straight
  • Mil-Type Grade

Search Keywords: 10572901

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1057290-1
Alias/AKA:
3052-1201-10
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tray
Type:
Type N
Impedance:
50 Ohm
Operating Frequency:
0 to 11 Hz to GHz
Gender:
RCP
Mounting:
Flange Mount
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
N/A
Operating Temperature:
-65 to 165 °C
Dimension:
36.6 x 25.4 x 25.4 mm

IN STOCK: 515

Can Ship immediately

MOQ for out of Stock Qty: 250

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
1
$27.81
50
$18.97
100
$18.69
250
$18.03
500
$17.53
750
$17.49
1,000 +
$17.45
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
