1-338313-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-338313-2

9POS.HD-20 REC.ASSY ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

1-338313-2 is a 9-way subminiature D-type socket connector designed for straight mounting applications with solder termination. It features boardlocks and 4-40 inserts for secure PCB mounting, with a tin-plated steel front shell and black glass-filled polyester housing rated UL 94V-0 for flammability. The phosphor bronze socket contacts have 0.76µm gold plating in the contact area, providing a maximum current rating of 6A and insulation resistance of 5000 MO minimum. With a dielectric strength of 1000V AC and an operating temperature range of -55°C to +105°C, this connector is suitable for reliable signal and power connections in industrial, computing, and instrumentation applications.

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HDP-20
  • With Mating Connector Lock

Search Keywords: 13383132

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-338313-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
55
Package Type:
TRAY
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,856

Can Ship immediately

MOQ for In Stock Qty: 55

MOQ for out of Stock Qty: 440

Multiple: 55

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
55
$5.75
110
$5.69
275
$5.68
440
$5.65
880
$5.45
1,320
$5.33
1,760 +
$5.31
Supplier's Standard Package
