1658613-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1658613-2

25 Position D-Sub Plug, Male Pins Connector ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1658613-2 is a 25-position Amplimite D-sub Plug with phosphor bronze, duplex plated gold on mating end, bright tin on termination end, entire contact under plated nickel, tin-plated steel front shell and black thermoplastic (UL94V-0) housing, cover and cable stabilizer. With standard mounting holes. IDC contact termination. TE Connectivity, the industry leader in AMPLIMITE D-Subminiature solutions, provides a complete range of quality, time-tested D-sub connectors that have become the standard in the D-Sub industry. TE Connectivity's complete line of D-Subminiature Connectors range from right-angle and vertical-posted connectors and cable connectors to the AMPLIMITE .050 Series D-Sub connectors Applications Computers & Computer Peripherals

Product Highlights:

  • Connector
  • Product Series = HDF-20 (Ribbon Cable)
  • Number of Positions = 25
  • Plug
  • With Contacts

Search Keywords: 16586132

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658613-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
40
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
IDT
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold Over Nickel,Gold Over Palladium Nickel Over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 2,801

Ships today, if you order in

On Order: 1,285   can ship 11/23/26

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5
$7.19
40
$4.21
80
$4.00
120
$3.92
280
$3.76
520
$3.62
1,000 +
$3.56
Supplier's Standard Package
Log in for special pricing
