1-87499-2 by te connectivity / amp brand
Image is representational - see mfr. specs

1-87499-2

TE Connectivity / AMP Brand

06 MODIV HSG COMP SR .100CL ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-87499-2 is a single-row receptacle housing assembly part of the AMPMODU Mod IV Interconnection System, designed for wire-to-board connections with dual entry and end-stackable configuration. The housing features a 0.100 inch by 0.100 inch [2.54 x 2.54 mm] centerline spacing with low-profile design and 0.200 inch [5.08 mm] tine spacing, constructed from glass-filled thermoplastic material rated 94V-0. The contact area includes localized gold plating with duplex plating options (Plating A, B, or C) on matte tin solder areas, all over 0.00127 inch [0.00127 mm] nickel, and the assembly is RoHS compliant. This receptacle housing is suitable for applications requiring reliable multi-position interconnections in compact, stackable configurations, with contact current ratings of 3 amperes and termination resistance of 12 milliohms maximum for beryllium copper contacts.

Product Highlights:

  • Connector
  • Without Contacts
  • Housing Gender = Connector - Receptacle
  • Housing Accepts Contact Type = Receptacle
  • 2.54 mm Centerline

Search Keywords: 1874992

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-87499-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
6
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
3/Contact A
Operating Temperature:
-65 to 105 °C

IN STOCK: 5,491

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 49 Weeks

Price (USD)

Qty
Unit Price
50
$0.7577
500
$0.4989
1,000
$0.4562
2,500
$0.4286
5,000
$0.4132
7,500
$0.4112
10,000
$0.4091
15,000 +
$0.4057
