2-111196-5 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

2-111196-5

Wire-To-Board Connector - 1.27 mm - 10 Contacts - Receptacle - AMPMODU System 50 Series - IDC / IDT. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1445692-4 is AMPMODU System 50 series Connector includes a wide variety of high density board-to-board (thru-hole and surface-mount) and cable-to-board connectors. The AMPMODU System 50 is composed of one and two-row receptacles and post headers on 0.050x0.100-inch (1.27x2.54mm) spacing between contacts for extreme density and efficient use of printed circuit board area. AMPMODU System 50 receptacles and header assemblies can be categorized in three groups, board-mount headers, board-mount receptacles and cable-to-board receptacles. Receptacle contacts and mating 0.0150inch (0.38mm) square posts are formed from high conductivity copper alloy and are selectively plated with gold to promote higher performance and reliability. Board-mounted thru-hole post headers and receptacle connectors are available for right-angle and vertical mating configurations. Surface-mounted connectors are available in vertical, double row styles for parallel stacking applications.

Product Highlights:

  • Receptacle Assembly
  • Number of Positions = 10
  • Number of Rows = Dual
  • With Mating Connector Lock
  • Wire/Cable Type = Ribbon Cable

Search Keywords: 21111965

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-111196-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
110
Package Type:
TRAY
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
RCP
Mounting:
Cable Mount
Pitch:
1.27 mm
Number of Contacts:
10
Maximum Voltage Rating:
30 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C

IN STOCK: 872

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 413

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5
$7.25
100
$5.90
250
$5.62
413
$5.61
825
$5.60
1,238
$5.58
1,650 +
$5.57
Log in for special pricing

Tools/3D Models

Product Guides
