Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

284506-3

Pluggable Terminal Block - Right Angle - 3.5 mm - 3 Ways - 30 AWG - 14 AWG - 2 mm² - Screw. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 284506-3 is a 3-position green right-angle through-hole Pluggable Terminal Block made up of polyamide 6.6 housing. It has tin-plated phosphor bronze contact base and nickel-plated brass screw and it applies to wire.

Product Highlights:

  • Connector
  • Housing Color = Green
  • Not Stacked
  • Without Threaded Flange
  • Without Screw Flange

Search Keywords: 2845063

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
284506-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
IT
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
BOX
Type:
Eurostyle Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
3.5 mm
Number of Circuits:
3
Maximum Voltage Rating:
300 VAC
Maximum Current Rating:
11/Contact A
Wire Size:
14-30 AWG
Operating Temperature:
N/A
