776106-1

Name: 776106-1
Brand: Te Connectivity Amp Brand
SKU: 10491884
Price: 22.65 USD
Availability: InStock

TE Connectivity / AMP Brand

EXTRACTION TOOL ...

Datasheet

RoHS Compliant

Pack Packaging

Certificate of Compliance Guarantee

DESCRIPTION

776106-1 is an insertion/extraction tool designed for use with socket contact assembly P/N 776093-1 and pin P/N 95-6901-12. The tool is manufactured from Acetal (Delrin) material in white (natural) color, providing durability and precision handling during connector assembly operations. Key dimensions include an overall length of 53.7 mm, outer diameter of 7.3 mm, and inner diameters of 4.65 mm and 4.05 mm for proper contact engagement. This tool is commonly used in connector maintenance and assembly applications where precise insertion and extraction of contacts is required.

Product Highlights:

Potential Applications:

Search Keywords: 7761061

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

776106-1

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

3926909989

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
