DTP04-4P-E003 by te connectivity / deutsch automotive
Image is representational - see mfr. specs

DTP04-4P-E003

TE Connectivity / Deutsch Automotive

Conn Housing RCP 4 POS 6.71mm Crimp ST Cable Mount Gray Box Automotive ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DTP04-4P-E003 is a 4-position in-line receptacle connector from the DEUTSCH DT Family, designed for rugged industrial and commercial transportation applications. This connector features environmental sealing capabilities with wire sealing ranges accommodating 14–20 AWG (2.0–0.5 mm²) wire sizes using standard seals, and supports reduced diameter E-seals for thinner wire insulation (1.35–3.05 mm OD). The receptacle is configured with 4 cavities and measures 1.868 inches (47.45 mm) in overall length, 0.797 inches (20.24 mm) in height, and 0.820 inches (20.83 mm) in width. It is commonly used in harsh environments where moisture, dirt, salt, and road debris protection is critical, and pairs with the DTP06-4S plug connector for complete mated assemblies. The connector supports various modifications including welded flanges, sealed flanges with gaskets, and shrink boot adapters to meet diverse installation and environmental requirements.

Search Keywords: DTP044PE003

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DTP04-4P-E003
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount3496
Body Orientation:
Straight3485
Gender:
RCP3489
Termination Method:
Crimp3503
Number of Contacts:
4
Maximum Voltage Rating:
2503494VDC
Maximum Current Rating:
25/Contact A
Operating Temperature:
-55 to 125 °C

IN STOCK: 3

Can Ship immediately

Buy all 3 in-stock or the regular minimum order quantity of 5

On Order: 350   can ship 7/6/26

Stock lot only: 3

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
1
$8.339
5
$7.581
25
$7.210
50
$7.056
100
$6.932
250
$6.808
500
$6.798
1,000 +
$6.777
