SR4D4024 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

SR4D4024

Power Relay 24VDC 8A DPST-NO/DPST-NC(40mm 13mm 16.5mm) THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

TE Connectivity / P&B Brand part SR4D4024 is a reliable and high-performance power relay suitable for various applications. This 24VDC relay has a contact rating of 8A and is equipped with double-pole single-throw normally open and double-pole single-throw normally closed contacts. With a compact size of 40mm x 13mm x 16.5mm, it is easily mounted through-hole technology. The SR4D4024 relay ensures efficient power transfer and reliable switching, making it an ideal choice for electronic circuits where space is limited.

Product Highlights:

  • Safety Relay SR4 D/M
  • SR4 D/M Series
  • DC Actuating System
  • Contact Arrangement = 2 Form A & 2 Form B, DPST-NO & DPST-NC, 2 N/O & 2 N/C
  • Contact Current Rating = 8 Amps.

Search Keywords: SR4D4024

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
SR4D4024
Alias/AKA:
3-1415055-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CZ
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Package Type:
TUBE
Type:
Safety Relay
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Coil Current:
33.33 mA
Coil Resistance:
720 Ohm
Dimension:
40 x 13 x 16.5 mm
Operating Temperature:
-25 to 70 °C
Termination Style:
PC Pin
Contact Arrangement:
DPST-NO,DPST-NC
Contact Form:
2 Form A,2 Form B
Maximum Current Rating:
8 A
Mounting:
Through Hole

IN STOCK: 1,210

Can Ship immediately

On Order: 250   can ship 12/14/26
On Order: 500   can ship 10/25/27
On Order: 500   can ship 11/3/27

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 50 Weeks

Price (USD)

Qty
Unit Price
10
$18.33
30
$17.80
50
$17.60
100
$17.56
250
$17.52
500
$17.47
1,000 +
$17.43
