89126-0101 by 3m interconnect solutions

89126-0101

3M Interconnect Solutions

The 89126-0101 is a 26-contact IDC ribbon cable socket for .050" pitch cable, featuring a .100" x .100" mating grid and military-style polarization. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 89126-0101 is a 26-contact IDC (Insulation Displacement Connector) socket from the 891 series, designed for mass termination of .050" pitch ribbon cable. This preassembled connector is configured without a strain relief and includes a centerbump for polarization. The contacts are made of phosphor bronze with 30 μ” gold plating in the wiping area over a nickel underplating, ensuring a reliable connection. The connector body is made from gray, UL 94V-0 rated glass-filled polyester (PBT) and accommodates both 26 and 28 AWG stranded wire. With an operating temperature range of -55°C to +105°C, this socket is ideal for various wire-to-board applications in electronic equipment.

Search Keywords: 891260101

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
3M Interconnect Solutions
Part No:
89126-0101
Alias/AKA:
7100251796
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500

IN STOCK: 25

Ships today, if you order in

On Order: 3,000   can ship 6/24/26

Minimum Order Quantity: 25

Factory Lead-Time 11 Weeks

Price (USD)

Qty
Unit Price
25
$1.406
250
$1.069
500
$1.008
1,000
$0.960
2,500
$0.900
5,000
$0.896
7,500
$0.891
10,000 +
$0.887
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
