AF116-30-00-13 by abb
Image is representational - see mfr. specs

AF116-30-00-13

ABB

ABB-CONTACTORS,OLS,MMPS - AF RANGE, (116-370), 3-POLE ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AF116-30-00-13 is a 3-phase block contactor designed for motor starting, isolation, bypass, and distribution applications up to a maximum of 690 V. The contactor operates with a wide control voltage range of 100-250 V at 50/60 Hz and DC, providing flexible integration into various control systems. It features three main contacts (NO), a rated operational current of 160 A at 40°C in AC-1 duty and 116 A at 55°C in AC-3 duty at 380-440 V, with a rated breaking capacity of 8 × Ie and making capacity of 10 × Ie according to IEC 60947-4-1. The device has a mechanical durability of 5 million cycles and operates with a maximum electrical switching frequency of 300 cycles per hour for AC-1 and AC-3 duties. Its compact dimensions (150 mm height × 90 mm width × 126 mm depth) and double clamp terminal type make it suitable for industrial control panels and motor control centers where reliable switching and long service life are essential.

Search Keywords: AF116300013

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ABB
Part No:
AF116-30-00-13
Unit of Measure:
Per Each
RoHS:
No
COO:
SE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Maximum Current Rating:
160 A
Contact Arrangement:
3PST-NO
DC Coil Voltage:
N/A
AC Coil Voltage:
100 to 250 V
Maximum DC Voltage Rating:
N/A
Maximum AC Voltage Rating:
690 V
Termination Style:
N/A
Led Indicator:
No
Mounting:
N/A

IN STOCK: 3

Can Ship immediately

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$367.70
3
$358.46
5 +
$354.18
