EB21A-05-C by adam tech
Image is representational - see manufacturer specifications
Adam Tech Authorized Distributor

EB21A-05-C

Euro Block 5Pos - Box ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The EB21A-05-C is a Euro block terminal connector designed for secure wire-to-board connections in industrial control and power distribution applications. It features a green PA66 insulator rated UL 94V-0 with brass tin-plated contacts and a nickel-plated brass cage, providing reliable electrical performance and corrosion resistance. The connector is rated for 300V and 8A with a maximum contact resistance of 20 mO, an insulation resistance of 500 MO minimum at 500V DC, and a dielectric withstanding voltage of 2000 VAC for 1 minute. It accommodates wire sizes from 22–16 AWG (1.0 mm²) with a strip length of 5–6 mm and operates across a temperature range of -40°C to +105°C. The M2.5 steel zinc-plated screw provides a torque rating of 0.4 Nm (3.6 lb-in) for secure termination, and the product is lead-free and RoHS compliant, making it suitable for modern industrial and commercial equipment.

Search Keywords: EB21A05C

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Adam Tech
Part No:
EB21A-05-C
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536690000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
BOX

IN STOCK: 607

Ships today, if you order in

Minimum Order Quantity: 200

Multiple: 200

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
200
$0.4712
600
$0.4448
1,000
$0.4324
2,600
$0.4093
5,000
$0.3936
7,600
$0.3474
10,000
$0.3414
15,000 +
$0.3326
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
