MS3476L14-15P

The MS3476L14-15P is a MIL-DTL-26482 Series 2 straight plug connector with a size 14 aluminum shell, electroless nickel finish, and a 15-contact pin arrangement. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Bulk Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MS3476L14-15P is a miniature cylindrical straight plug connector designed to meet MIL-DTL-26482, Series 2 standards. It utilizes a three-point bayonet coupling system for quick and secure mating, with rear-insertable and rear-releasable crimp contacts. This connector features a size 14 aluminum shell with a fluid-resistant, electroless nickel finish (Class L). The 14-15 insert arrangement contains 15 pin contacts, consisting of one size 16 contact and fourteen size 20 contacts. With an operating temperature range of -55°C to 200°C and a durability of 500 mating cycles, it is ideal for demanding military and industrial applications where reliable, environmentally sealed connections are critical.

Search Keywords: MS3476L1415P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Aero-Electric
Part No:
MS3476L14-15P
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694020
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
Bulk

IN STOCK: 51

Ships today, if you order in

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
1
$101.42
5
$81.62
10
$78.63
25
$67.83
50
$64.27
100
$63.70
250 +
$63.11
