HYR15550-1520 by aleph america

HYR15550-1520

Aleph America

Switch Reed -N.O./N.C. - 0.25A- 100VDC - 3VA- 200mOhm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Aleph HYR-1555 - Form "C" Reed Switch Contact Form 1C Contact Position 1 O Contact Material Ruthenium 3 Max. Contact Rating 3W Max. Switching Voltage 100VDC Max. Switching current 0.25A Max. Initial Contact Resistance 200mW Pull in Value (AT) 15 -50 Min. Drop out Value (AT) 7 Min. Breakdown Voltage 2 200VDC Max. Contact Capacitance 0.8pF Min. Insulation Resistance 10 9 W Typ. Resonant Frequency 2.4kHz Electrical Life (Resistive loads) 10 8 (10mVDC, 10 µ A) 2 X 10 6 (12VDC, 250mA) Features Single pole, double throw

Search Keywords: HYR155501520

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Aleph America
Part No:
HYR15550-1520
RoHS:
Yes
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Switch Configuration:
N.O./N.C.
Device Sensitivity Range:
15 to 50 AT
Mounting:
PCB Through Hole
Maximum AC Voltage Rating:
N/A
Maximum DC Voltage Rating:
100 V
Maximum Current Rating:
0.25 A
Operating Temperature:
N/A
Terminal Type:
Axial Leads
Dimension:
52.6 x 2.7 mm
Glass Length:
14.3 mm
Contact Material:
Ruthenium Oxide/Rhodium

IN STOCK: 200

Ships today, if you order in

Minimum Order: 200

Multiple: 200

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
200
$1.215
400
$1.154
800
$1.102
1,600 +
$1.040
