Image is representational - see mfr. specs

1178C-SL002

The 1178C-SL002 is an 8-conductor, 22 AWG multi-conductor cable with a PVC jacket for communication and control applications. ...

Datasheet

RoHS Compliant

Reel Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 1178C-SL002 is an 8-conductor cable designed for use in communication and control systems. It features eight 22 AWG stranded (7/30) tinned copper conductors with color-coded PVC insulation for easy identification. The cabled conductors are enclosed in a slate PVC jacket with a nominal outer diameter of 0.230 inches. This cable has a voltage rating of 300 VRMS and an operating temperature range of -20Â°C to 80Â°C. Compliant with UL, CSA, and RoHS standards, it is suitable for the internal or external wiring of electronic equipment.

Product Highlights:

Potential Applications:

Search Keywords: 1178CSL002

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1178C-SL002

Alias/AKA:

1178C-SLATE-500

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
