1299/10C-SL005

Name: 1299/10C-SL005
Brand: Alpha Wire
SKU: 10116774
Price: 483.19 USD
Availability: InStock

A 10-conductor, 22 AWG shielded communication and control cable featuring a PVC jacket and insulation. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 1299/10C-SL005 is a multi-conductor shielded cable designed for communication and control applications. It is constructed with ten 22 AWG stranded tinned copper conductors, each with PVC insulation and color-coded for easy identification. An overall aluminum/Mylar tape shield with a 22 AWG tinned copper drain wire provides effective protection against external interference. The cable is finished with a slate-colored, flame-retardant PVC jacket, has a nominal outer diameter of 0.268 inches, and is rated for a temperature range of -20Â°C to 80Â°C. Compliant with UL, CSA, and RoHS standards, this cable is ideal for a variety of general-purpose control, instrumentation, and audio systems.

Product Highlights:

Potential Applications:

Search Keywords: 129910CSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1299/10C-SL005

Alias/AKA:

1299/10C-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
