1854-BK005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

1854-BK005

Hook-up Wire 24AWG 1.09mm Tinned Copper Black 600V - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1854-BK005 is a single-conductor hookup wire designed for general-purpose electrical connections and wiring applications. It features a 24 AWG tinned copper conductor with a nominal 0.010" PVC insulation wall, providing an overall diameter of 0.044 ± 0.002 inches. The wire is rated for 600 V RMS operation and complies with military specifications MIL-W-76B TYPE LW (90°C / 300 V RMS) and MIL-W-16878E/1 (105°C / 600 V RMS), with an operating temperature range of -55°C to +105°C. Key electrical properties include a nominal inductance of 0.05 µH/ft and a conductor DC resistance of 25 O/1000ft at 20°C. This wire is ideal for instrumentation, control circuits, and general-purpose wiring where reliable, temperature-stable connections are required, and it is RoHS 2 and RoHS 3 compliant.

Search Keywords: 1854BK005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
1854-BK005
Alias/AKA:
1854-BLACK-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
24 AWG
Bunch Stranding:
7x32
Conductor Material:
Tinned Copper
Cable Diameter:
1.09 mm
Maximum Voltage Rating:
600 V
Operating Temperature:
-55 to 105 °C
Color:
Black

IN STOCK: 10

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$52.47
5
$46.81
10
$45.42
25
$44.10
50
$41.68
100
$40.57
250 +
$40.04
