1857-WH005

Alpha Wire

Hook-up Wire 18AWG 1.73mm Tinned Copper - White - 600V - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 1857-WH005 is an 18 AWG single-conductor hookup wire manufactured by Alpha Wire, designed for general-purpose electrical connections in applications requiring reliable insulation and voltage performance. The wire features a tinned copper conductor with 7/26 stranding and a 0.010" nominal PVC insulation wall, providing a total outer diameter of 0.068 ± 0.002 inches. It is rated for 600 V RMS at 105°C and complies with military specification MIL-W-16878E/1, with an operating temperature range of -55°C to +105°C. The wire exhibits a conductor DC resistance of 6.3 O/1000 ft at 20°C and an inductance of 0.04 µH/ft, with a maximum pull tension of 13.9 lbs and a bend radius of 10× cable diameter. This hookup wire is ideal for laboratory equipment, control circuits, and general wiring applications where durability and compliance with military standards are required.

Product Highlights:

Potential Applications:

Search Keywords: 1857WH005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1857-WH005

Alias/AKA:

1857-WHITE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
