1891C-SL005

Name: 1891C-SL005
Brand: Alpha Wire
SKU: 10118989
Price: 274.58 USD
Availability: InStock

Multi-Conductor Cable Polyvinyl Chloride 2 Conductors 14AWG 6.98mm 300VAC - Slate - 30.48m (100ft)/Spool ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 1891C-SL005 is a two-conductor control cable featuring 14 AWG tinned copper conductors with individual PVC insulation (0.020" wall) and an overall PVC jacket (0.020" wall, 0.260" diameter). The cable is constructed with 2 components cabled at 3.7 twists per foot minimum and is color-coded with black and red conductors per Alpha Wire Color Code D. It is rated for 300V RMS at 75°C and complies with UL Type CL2 or C(RU) AWM standards at 80°C for 300V FT1 applications. The cable exhibits a characteristic impedance of 60O, capacitance of 36 pF/ft at 1 kHz, and a conductor DC resistance of 2.8O/1000ft at 20°C, making it suitable for low-voltage control, instrumentation, and signal transmission applications requiring reliable performance across a temperature range of -20°C to 80°C.

Product Highlights:

Potential Applications:

Search Keywords: 1891CSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1891C-SL005

Alias/AKA:

1891C-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
