1898/5C-SL005

Name: 1898/5C-SL005
Brand: Alpha Wire
SKU: 10119119
Price: 270.43 USD
Availability: InStock

Multi-Conductor Cable Polyvinyl Chloride 5 Conductors 18AWG 6.75mm 300VAC - Slate - 30.48m (100ft)/Spool ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 1898/5C-SL005 is a five-conductor control cable featuring 18 AWG stranded tinned copper conductors (16/30 strand count) with individual PVC insulation and an overall PVC jacket. The cable is constructed with 5 conductors cabled together at a minimum twist rate of 4.0 twists per foot, with color coding following Alpha Wire Color Code D (Black, Red, White, Green, Orange). It is rated for 300V RMS at 80°C per UL AWM/STYLE 2509 and meets CSA CMG FT4 and EU Low Voltage Directive requirements. The cable operates reliably over a temperature range of -20°C to +80°C with a maximum bend radius of 10 times the cable diameter and a maximum pull tension of 63 lbs. This cable is ideal for control, instrumentation, and general-purpose wiring applications in industrial equipment, machinery, and control panels where multiple signal or power conductors are required in a compact, flexible format.

Product Highlights:

Potential Applications:

Search Keywords: 18985CSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1898/5C-SL005

Alias/AKA:

1898/5C-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
