Image is representational - see mfr. specs

2841/1-WH005

Name: 2841/1-WH005
Brand: Alpha Wire
SKU: 10120966
Price: 158.98 USD
Availability: OutOfStock

Alpha Wire

White - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 2841/1-WH005 is a single-conductor hookup wire featuring a 30 AWG solid silver-plated copper (SPC) conductor with a nominal 0.006" wall PTFE insulation, providing an overall diameter of 0.022" ± 0.002". It is rated for 250 V RMS and exhibits a nominal inductance of 0.06 µH/ft with a conductor DC resistance of 104 O/1000 ft at 20°C. The wire operates across a temperature range of -60°C to +200°C and supports a maximum pull tension of 0.79 lbs, with a minimum bend radius of 10 times the cable diameter. This wire is manufactured in compliance with MIL-W-16878/6 (Type ET) and NEMA HP3-ETXBBA specifications, and is RoHS 2/RoHS 3 compliant. It is commonly used in laboratory equipment, test instrumentation, and aerospace applications where high-temperature performance and reliable signal transmission are required.

Product Highlights:

Potential Applications:

Search Keywords: 28411WH005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

2841/1-WH005

Alias/AKA:

2841/1-WHITE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
