2842/7-RD005

Alpha Wire

Hook-up Wire 28AWG 0.68mm Silver Plated Copper - Red - 250V - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 2842/7-RD005 is a single-conductor hookup wire designed for general-purpose electrical applications requiring reliable insulation and conductivity. It features a 28 AWG (7/36) stranded silver-plated copper conductor with a nominal 0.006" wall PTFE insulation, providing excellent dielectric properties and chemical resistance. The wire is rated for 250V RMS operation and maintains performance across a temperature range of -60°C to +200°C, with a maximum pull tension of 1.37 lbs and a minimum bend radius of 10 times the cable diameter. It complies with military specification MIL-W-16878/6 (Type ET) and NEMA HP3-ETXBGB standards, and is RoHS 2 and REACH compliant. This wire is commonly used in instrumentation, aerospace, and high-temperature applications where superior insulation integrity and temperature stability are essential.

Product Highlights:

Potential Applications:

Search Keywords: 28427RD005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

2842/7-RD005

Alias/AKA:

2842/7-RED-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
