2843/19-GR005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

2843/19-GR005

Hook-up Wire 26AWG 0.8mm Silver Plated Copper- Green - 250V - 30.48m (100ft)/Spool ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 2843/19-GREEN-100 is a high-performance hook-up wire designed for the internal wiring of electronic equipment. It features a 26 AWG stranded (19/38) silver-plated copper conductor and a durable, green PTFE insulation with a nominal 0.006" wall thickness. This wire is rated for 250 VRMS and has an extensive operating temperature range from -60°C to 200°C. Compliant with MIL-W-16878/6 (Type ET) specifications, it is well-suited for military, aerospace, and other high-reliability applications requiring robust performance in demanding thermal environments.

Search Keywords: 284319GR005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
2843/19-GR005
Alias/AKA:
2843/19-GREEN-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
26 AWG
Bunch Stranding:
19x38
Conductor Material:
Silver Plated Copper
Cable Diameter:
0.8 mm
Maximum Voltage Rating:
250 V
Operating Temperature:
-60 to 200 °C
Color:
Green

IN STOCK: 5

Ships today, if you order in

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$174.41
5
$169.56
10
$167.24
20
$166.82
50
$160.64
100 +
$156.52
