3048-OR005

Alpha Wire

Hook-up Wire 28AWG 1.19mm Tinned Copper - Orange - 300VAC - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 3048-OR005 is a single-conductor hookup wire designed for general-purpose electrical connections and wiring applications. It features a 28 AWG (7/36) tinned copper conductor with a nominal 0.016" wall PVC insulation, providing a total outer diameter of 0.047" ± 0.002". The wire is rated for 300 V RMS and operates reliably across a temperature range of -40°C to +105°C, meeting both UL AWM/STYLE 1007 (80°C) and AWM/STYLE 1569 (105°C) standards, as well as CSA International TR-64 and FT1 specifications. With a maximum pull tension of 1.37 lbs and a bend radius of 10X cable diameter, this wire is ideal for internal wiring in electronic equipment, control circuits, and general hookup applications where compact gauge and reliable insulation are required.

Product Highlights:

Potential Applications:

Search Keywords: 3048OR005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3048-OR005

Alias/AKA:

3048-ORANGE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99
