3049-WH005

Name: 3049-WH005
Brand: Alpha Wire
SKU: 10121772
Price: 93 USD
Availability: InStock

Alpha Wire

Hook-up Wire 26AWG 1.3mm Tinned Copper - White - 300VAC - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 3049-WH005 is a single-conductor hookup wire designed for general-purpose electrical interconnections in equipment and control systems. It features a 26 AWG tinned copper conductor (7/34 stranding) with a nominal 0.016 inch PVC insulation wall, achieving an overall diameter of 0.051 ± 0.002 inches. The wire is rated for 300 V RMS and operates across a temperature range of -40°C to +105°C, with UL recognition under AWM/STYLE 1007 (80°C/300 V) and AWM/STYLE 1569 (105°C/300 V), plus CSA TR-64 (90°C) and FT1 certifications. It exhibits a nominal conductor DC resistance of 41 O/1000 ft at 20°C and an inductance of 0.08 µH/ft. The white insulation variant is RoHS 2 and RoHS 3 compliant, making it suitable for industrial control panels, instrumentation, and consumer electronics requiring reliable low-voltage signal and power distribution.

Product Highlights:

Potential Applications:

Search Keywords: 3049WH005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3049-WH005

Alias/AKA:

3049-WHITE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
