3051-YL005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

3051-YL005

Hook-up Wire 22AWG 1.62mm Tinned Copper - Yellow - 300VAC - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3051-YL005 is a single-conductor hookup wire designed for general-purpose electrical interconnections and low-voltage applications. It features a 22 AWG stranded copper conductor (7/30 stranding) with a nominal 0.016" wall PVC insulation, providing a total outer diameter of 0.062" ± 0.002". The wire is rated for 300 V RMS and operates across a temperature range of -40°C to 105°C, with a maximum pull tension of 5.5 lbs and a minimum bend radius of 10 times the cable diameter. It exhibits a nominal inductance of 0.06 µH/ft and a conductor DC resistance of 16.2 O/1000 ft at 20°C. This wire is commonly used in control circuits, instrumentation, and general wiring applications where compact gauge and reliable insulation are required.

Search Keywords: 3051YL005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
3051-YL005
Alias/AKA:
3051-YELLOW-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
22 AWG
Bunch Stranding:
7x30
Conductor Material:
Tinned Copper
Cable Diameter:
1.62 mm
Maximum Voltage Rating:
300 VAC
Operating Temperature:
-40 to 105 °C
Color:
N/R
  Different packaging options available.  See Alternatives

IN STOCK: 8

Ships today, if you order in

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$55.11
5
$49.17
10
$47.71
25
$45.66
50
$43.79
100
$42.62
250 +
$42.05
