3055-BK005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

3055-BK005

The 3055-BK005 is an 18 AWG single-conductor hook-up wire with PVC insulation. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3055-BK005 is an 18 AWG hook-up wire featuring a single tinned copper conductor with 16/30 stranding. It is constructed with a nominal 0.016-inch wall of PVC insulation, resulting in an overall diameter of 0.079 inches. This wire is rated for 300 VRMS and has an operating temperature range of -40°C to 105°C. It meets multiple industry standards, including UL AWM Style 1569 and CSA TR-64, and carries a VW-1 flame rating. Compliant with RoHS and REACH directives, this wire is ideal for the internal wiring of electronic and electrical equipment.

Search Keywords: 3055BK005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
3055-BK005
Alias/AKA:
3055-BLACK-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544110050
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
18 AWG
Bunch Stranding:
16x30
Conductor Material:
Tinned Copper
Cable Diameter:
2.05 mm
Maximum Voltage Rating:
300 VAC
Operating Temperature:
-40 to 105 °C
Color:
N/R
  Different packaging options available.  See Alternatives

IN STOCK: 10

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$78.27
5
$69.84
10
$67.75
25
$62.19
50
$62.04
100
$60.53
250 +
$58.21
